TOP-Parkolor-60HD-3D

ASTRA 180 HDL New

Developed for demanding environments in indoor or outdoor events, Astra 180HDL offers a range of IP65 LED fixtures combining power, optical precision and long-lasting reliability.

Thanks to its 15W RGB + Lime 18 LEDs and 12° fixed-angle, Astra 180HDL provides rich, subtle colour mixing, delivering both deep, saturated colours and accurately calibrated whites, with smooth fades and excellent uniformity.
Astra 180 HDL is ideal for lighting live shows, scenic elements and architectural façades. Its die-cast aluminium housing ensures optimal thermal management and robustness, perfectly suited for intensive professional use.

Designed to adapt to any configuration, Astra 180 HDL offers a selection of clip-on optical filters in 20°, 40°, 60°, and 60 × 10°, allowing the beam angle to be adjusted from wide wash applications to more directional uses.

In terms of control, Astra 180 HDL provides advanced flexibility: the fixtures can be operated via a Bluetooth app, enabling mesh networking, remote configuration, and fast fixture setup. For traditional installations, wired DMX control ensures seamless integration with any lighting console and enables remote adjustment of modes and addressing.

astra180HDL_vert

ASTRA 180 HDL in détails

  • 12 X 15W LED RGB+Lime
  • Luminous flux: 6,334 lumens
  • Illuminance @5m: 4,976 lux@12°
  • Opening angle: 12°, 20°,40°,60°,60x10° and frost optional filters
  • White macros: 2,700°K to 10,000°K
  • Dimmer: 16-bit
  • 4 dimmer curves
  • BC Color System ®
  • Bluetooth App control
  • DMX, RDM
  • Power Consumption: 180 W
  • Weight: 5,5 Kg
  • Connectors: Seetronic True one in/out and XLR 5
  • IP65 RATING

LED-18X15W
LEDs 18 x 15W
RGBL
RGBW: Red+Green+Blue LEDs.
frost-filter

16 bit Dimmer: 16-bit intensity control at 65,535 levels.

rdm

RDM: Remote Device Management.

filter-60-x-10
Angle-(Aperta)

Zoom from 7° to 53°.

ip65
WET

IP65: Product suitable for outdoor use.

Support

Videos

Photos







astra180HDL © LI (5)
astra180HDL_filtre
astra180HDL © LI (7)
astra180HDL © LI (3)
astra180HDL © LI (4)
astra180HDL © LI (9)

Interested in this product?

Leave us your contact details and our sales representatives will get back to you as soon as possible.
